THE RIDGEWOOD HOUSE L, 3 CAR House Plan MRCS-10054
Floorplan Drawings
What is included?
All plans are drawn at 1/4” scale or larger and include:
– Foundation Plan: Drawn to 1/4″ scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
– Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
– House Plan(s): Detailed plans, drawn to 1/4″ scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
– Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
– Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*See important information before purchasing
